SBR is a registered trademark of Diodes Incorporated.
SBR20A60
Document number: DS30965 Rev. 11 - 2
2 of 5
www.diodes.com
August 2012
? Diodes Incorporated
SBR20A60CT
SBR20A60CTB
SBR20A60CTFP
Maximum Ratings (Per Leg)
(@TA
= +25°C, unless otherwise specified.)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
VRRM
VRWM
VRM
60 V
Average Rectified Output Current Per Device (Per Leg)
10
(Total)
IO
20
A
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
IFSM
180 A
Peak Repetitive Reverse Surge Current (2μS - 1Khz)
IRRM
3 A
Isolation Voltage (ITO-220AB Only)
From terminal to heatsink t = 3 sec.
VAC
2000 V
Repetitive Peak Avalanche Power (1μs, +25oC)
PARM
7000 W
Thermal Characteristics (Per Leg)
Characteristic Symbol Value Unit
Typical Thermal Resistance
Package = TO-220AB
Package = TO263
Package = ITO-220AB
RθJC
2
2
4
oC/W
Operating and Storage Temperature Range
TJ, TSTG
-65 to +150 oC
Electrical Characteristics
(Per Leg)
(@TA
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Forward Voltage Drop
VF
-
-
0.47
-
0.65
0.56
0.79
V
IF
= 10A, T
J
= +25oC
IF
= 10A, T
J
= +125oC
IF
= 20A, T
J
= +25oC
Leakage Current (Note 6)
IR
- - 0.5 100
mA
VR
= 60V, T
J
= +25oC
VR
= 60V, T
J
= +125oC
Notes: 6. Short duration pulse test used
to minimize self-heating effect.
